PP Chamber Filter Press Plate — High-Strength Industrial Filtration
Core solid-liquid separation component for filter press systems. Made from 100% virgin polypropylene
with precision CNC-machined drainage channels. Compatible with all standard automatic and hydraulic filter presses.
20+ years of manufacturing from Jingjiang Bestcome Machinery Co., Ltd — ISO 9001 certified, exported worldwide.
CNC Precision ±0.1mm
Corrosion Resistant
320–2000 mm
Custom Sizes
At a Glance
PP Chamber Filter Plate — Key Parameters
Key Features
Precision CNC Machining
All plates machined to ±0.1mm flatness tolerance. Ensures perfect sealing between plates and zero leakage during operation.
High-Pressure Resistance
Engineered for 0.6–1.0 MPa continuous operation. Reinforced PP structure resists deformation under heavy loads.
Chemical & Corrosion Resistant
100% virgin PP material resists acids, alkalis, and harsh chemicals. Suitable for aggressive industrial slurries.
Optimized Drainage Channels
Pip-textured surface with precision-engineered drainage grooves. Maximizes filtrate flow rate and ensures fast dewatering.
Full Size Customization
Standard sizes 320–2000 mm. Custom dimensions, cake thickness (25–50mm), handle position, and feed port design available.
Universal Compatibility
Fits all standard automatic, hydraulic, and manual filter press systems. Replacement plates for any brand.
Technical Specifications
| Model | Outer Dim. (mm) | Inner Dim. (mm) | Cake Thick. | Plate Thick. | Feed Port | Pressure | Weight |
|---|---|---|---|---|---|---|---|
| 320 | 370×370 | 320×320 | 30 mm | 50 mm | DN40 | 0.6–1.0 | 5 kg |
| 450 | 505×505 | 450×450 | 30 mm | 50 mm | DN40 | 0.6–1.0 | 8.5 kg |
| 630 | 705×705 | 630×630 | 30 mm | 50 mm | DN65 | 0.6–1.0 | 17 kg |
| 800 | 800×800 | 725×725 | 30 mm | 60 mm | DN65 | 0.6–1.0 | 27 kg |
| 1000 | 1000×1000 | 920×920 | 30 mm | 60 mm | DN80 | 0.6–1.0 | 39 kg |
| 1250 | 1250×1250 | 1150×1150 | 30 mm | 65 mm | DN100 | 0.6–1.0 | 67 kg |
| 1500 | 1500×1500 | 1390×1390 | 30 mm | 70 mm | DN125 | 0.6–1.0 | 100 kg |
| 2000 | 2000×2000 | 1860×1860 | 30 mm | 85 mm | DN200 | 0.6–1.0 | 200 kg |
Additional Specs: Filter cake thickness: 25–50 mm (customizable). Feed types: center / corner / top feed.
Material: 100% virgin polypropylene (optional fiber-reinforced composite for high-abrasion applications).
All plates CNC machined for uniform drainage. Gasket styles: non-gasketed or CGR (O-ring sealed) for zero-leak applications.
Applications
Mining & Minerals
Tailings dewatering, concentrate filtration, mineral slurry processing
Chemical Industry
Pigment, dye, catalyst, and acid-base slurry filtration
Wastewater Treatment
Municipal sludge, electroplating, and industrial effluent dewatering
Ceramics & Stone
Kaolin processing, stone cutting slurry, ceramic glaze recovery
Get Your Custom Quote
Tell us your plate size, slurry type, and quantity — we’ll provide a detailed quotation
with CAD drawings and technical recommendations.
